SOFTLINE

High performance module

Very high heating and cooling capacity
With optional absorbers: Advanced sound absorption values (class B)
Powerful and energy efficient
Simple installation; option to pivot modules down
Formes: Curve, Roof & Base (more on request)
Anodised profiles available
Components can be integrated

Aesthetic ceiling with high cooling capacity

SOFTLINE affords a wide range of installation options. With its sleek design, the ceiling fits perfectly in showrooms, offices and corridors. Lighting can be installed between the aluminium profiles or beneath the profiles in the form of pendant lights. The SOFTLINE high performance modules are available as Base, Roof and Curve versions.

Dimensions:

Installation height: min. 180 mm

Standard dimensions:
- Length: 600 – 2500 mm
- Width: 380 - 1290 mm
- Height: 40 mm (Base) / 50 mm (Roof, Curve)
- Pipe rows: 3 – 10
- Tube distances: 130 mm
Special dimensions on request

Capacity water:

Cooling: up to 142 W/m² (ΔT: 8 K)
Heating: up to 135 W/m² (ΔT: 15 K)

Acoustics:

Optional:
Sound absorber structure with acoustic mat (mineral wool): αw up to 0,85
Sound absorption class B

Filter

Include Accessory documents

Document	Article	Document type	Date	Download
SOFTLINE_High performance module (pdf 1.63MB)	SOFTLINE	Technical catalogue	07/10/2024
Overview radiant ceiling systems (pdf 5.29MB)	Overview radiant ceiling systems	Brochure	07/10/2024
